23
2018/02
TBIP-L…-FDIO1-2IOL- Safe I/O channels
3.6 Universal Standard I/Os
The function description of the unsafe universal I/Os can be found in the separate documentation
Part 2: User
manual TBIP-L…-FDIO1-2IOL – Standard I/O channels.
3.7 IO-Link Master Channels
The function description of the unsafe IO-Link master channels can be found in the separate docu-
mentation Part 3: User manual TBIP-L…-FDIO1-2IOL - IO-Link
master.
3.8 Configuration Memory
A pluggable memory stick is included in the scope of delivery of TBPN-L1-FDIO1-2IOL. It serves for
storing the safety function configured via Turck Safety Configurator.
It allows to transfer the configuration of on
e device to another device (device exchange).
the safety function is configured via
Turck Safety Configurator (see chapter 8, Configuring with
Turck Safety Configurator and Rockwell Studio 5000).
3.8.1 Storing a Configuration
The safety function is automatically stored to the memory stick after a configuration has been
downloaded to the device via Turck Safety Configurator.
HINWEIS
Non-safety-related configurations as for example the IP address or the parameterization
of the IO-Link and the standard I/O channels will not be stored on the memory chip.
Storing a Configuration at Device Start
Prerequisites
Empty memory chip
Device has stored a valid configuration
Power supply switched-off
Procedure
Plug the empty memory chip into the device
Switch-on the power supply
The configuration will be loaded from the device t
o the memory stick during device start.
