3.8.5 Module Behavior and Configuration Transfer
Configuration Module
behavior
Diagnostics
Device
internal
External 
memory
Device/
memory
invalid/
none
invalid/
none
- Device start
Device not running
No Configuration Available
(page 94)
invalid/
none
valid - Device start
Device running
Configuration
Memory  device
-
valid invalid/
none
- Device start
Device running
Configuration
Device  memory
chip
-
valid valid equal Device start
Device running
-
valid valid unequal Device start
Device running
Configuration Mismatch
(page 94)
valid memory 
not plugged
- Device start
Devicenot running
No Memory Chip Plugged
(page 94)
valid Memory Chip is 
pulled
- Device running No Memory Chip Plugged
(page 94)
changed
during
operation
valid unequal Device running
Check of the new con-
figuration
Configuration
Device  memory
chip
