33
V01.0| 2017/04
TBPN-L1-FDIO1-2IOL - Standard IO-Link
4.1.6 Subindex 69: Extended Port Diagnostics
Structure of the Extended Port Diagnostics:
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 NO_SIO TCYC - - DS_F NO_DS - -
Byte 1 - WD MD PDI_H - PDI_E NO_PD -
Byte 3
Byte 4 Device status according to IO-Link specification (see
Device Status (page 34))
Diagnostic bit Meaning
NO_DS The parameterized port mode (see Parameters (page 14)) does not support data
storage.
Remedy:
– Change the parameterization of the port.
DS_F Error in the data storage, synchronization not possible
Possible causes:
– Connected device does not support data storage
– Overflow of the data storage buffer
Remedy:
– Connect a device that supports data storage.
– Clear the data storage buffer.
– Deactivate the data storage.
TCYC The device does not support the cycle time parameterized in the master.
Remedy:
– Increase the cycle time set in the master
NO_SIO The device does not support the standard DI mode (see parameter Mode (page
14)
).
Remedy:
– Select the IO-Link mode for this port.
NO_PD No process data available The connected
device is not ready for operation.
Remedy:
– Check the configuration
PDI_E The connected device reports invalid process data in accordance with IO-Link speci-
fication V1.0.
PDI_H The connected device reports invalid process data in accordance with IO-Link speci-
fication V1.1.
MD Missing device: No IO-Link device detected
Remedy:
– Check the IO-Link cable.
– Change the device.
WD Wrong device detected: one or more parameters of the connected device (Vendor ID,
Device ID, se
rial number) does not/do not match the data which are stored in the
master for this device.
Remedy:
– Change the device.
– Adapt the master parameterization (see parameter Mode (page 14))
Entity_
Port
IO-Link
subindex
Read
Write
Length Description
0 69 r max. 8 byte This object serves for reading the
Extended
Port Diagnostics.
