Properties of the Universal Standard I/O Channels (DXP Channels)
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
6
2.4 Process Data of the Universal Standard I/O Channels
2.4.1 Process image TBPN-L1-FDIO1-2IOL
Process Input Data – Complete Module
Process Input Data - Universal Standard I/O channels
NOTE
Further information about the parts of he process image of TBPN-L1-FDIO1-2IOL which
concern the safe I/O channels and the IO-Link channels can be found in the user manuals
Part 1: User manual – FDIO1-2IOL – Safety and Part 3: User manual – TBIP-L…-FDIO1-2IOL
– IO-Link master".
The parts, which are relevant for the standard I/O channels are shown in bold.
Word Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
Status
word
n see Status and Control Word (page 89)
Basic n + 1 …
n + 2
Status: 
universal I/O channels and IO-Link Master channels
Fieldbus
bits
n + 3
Safety-
Status
n + 4 … 
n + 10
Safe I/O channels,
see Process Input Data - Safe I/O Channels (page 92)
IO-Link
channels
n + 11 … 
n + 42
IO-Link process input data
Diagnos-
tics
n + 43 reserved Overcurrent diagnostics
n + 44
DXP diagnostics
reserved
n + 45 …
n + 46
IO-Link port diagnostics
IO-Link
Events
n + 47
…
n + 78
IO-Link Events
Module
status
n + 49 see Module Status (page 90)
Word Bit
15
Bit
14
Bit
13
Bit
12
Bit 
11
Bit 
10
Bit 
9
Bit 
8
Bit 
7
Bit 
6
Bit 
5
Bit 
4
Bit 
3
Bit
2
Bit 
1
Bit 
0
Basic n + 1 - DXP11
C5P2
DXP10
C5P4
DXP9
C4P2
DXP8 
C4P4
-
...
Diag-
nostics
n + 44 - SCO11 SCO10 SCO9 SCO8 -
