2.5.3 Process Output Data – IO-Link Master Channels
Word Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
Basic
n + 1 DXP15
C7P2
-DXP13
C6P2
------
…
IO-Link channels
n + 4
…
n + 19
IOL1 – process output data (connector C6)
Structure depends on the channel parameterization
n + 20
…
n + 35
IOL2 – process output data (connector C7)
Structure depends on the channel parameterization
Name Value Meaning
Cx M12-connector/female connector
Px Pin no.
DXPx DXP output
0 Output inactive
1 Output active, max. output current 0.6 A
IO-Link process output data
Process output data of the connected device
The order of the IO-Link process output data can be changed via the parameter "Process output data
mapping" ( s. page 14).
