Operating
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
94
Safe Unit Statu
Word Bit
15
Bit
14
Bit
13
Bit
12
Bit
11
Bit
10
Bit
9
Bit
8
Bit
7
Bit
6
Bit
5
Bit
4
Bit
3
Bit
2
Bit
1
Bit
0
n + 4 - SUU
M
SUC
M
SUP
M
s
Name Value
SUPM Safe Unit Protective Mode
0 active
1 not active
SUCM Safe Unit Configuration Mode
0 active
1 not active
SUUM Safe Unit Unknown Mode
0 active
1 not active
Error Codes
Code Name Meaning Remedy
64
(0x40)
Destination
address mismatch
The set IP address does not match
the parameterized IP address.
65
(0x41)
Invalid
destination
a
ddress
The set destination IP address is not
valid. A
ddresses 0x00 and 0xFF are
not allowed.
66
(0x42)
Invalid source
a
ddress
The set source IP address is not valid.
Addresses 0x00 and 0xFF are not
allowed.
67
(0x43)
Invalid
watchdog time
Invalid value for watchdog time
(F_WD_
Time, F_WD_Time 2).
A watchdog time of 0 ms is not
all
owed.
68
(0x44)
SIL value exceeded The required SIL level is not sup-
ported by the device.
69
(0x45)
Invalid
Length of CRC2
Not relevant for CIP Safety
70
(0x46)
Invalid PROFIsafe
version
71
(0x47)
CRC1 mismatch
72
(0x48)
Invalid PROFIsafe
paramete
rs
75
(0x4B)
iParameter CRC
mismatch
Memory and F-Config Status
Name Code Meaning
PMS 512 No Memory Chip Plugged
NCNF 513 No Configuration Available
CNFMV 514 Configuration Mismatch
COMLO 516 Communication loss
FERR 519 Fatal Error
Parameter change
Device restart
Parameter change
Device restart
Parameter change
Device restart
Parameter change
Device restart
Parameter change
Device restart
