TBIP-L…-FDIO1-2IOL
Part 3 – TBIP-L…-FDIO1-2IOL – Standards IO-Link channels
Table of Contents
15 About this User Manual 3
15.1 Documentation Concept 3
15.2 Target Groups of these Operating Instructions 3
15.3 Additional Documents 3
15.4 Explanation of Symbols Used 4
15.5 Manufacturer and Service 4
16 Properties of the IO-Link channels 5
16.1 Device structure 6
16.2 Power supply of the IO-Link ports 7
16.2.1 Class A/B supply 7
16.2.2 Safe shutdown of IOL2 (at C7) 7
16.3 Technical data 8
16.4 Connecting 9
16.5 Process Data of the IO-Link Master Channels 10
16.5.1 Process Image TBIP-L…-FDIO1-2IOL 10
16.5.2 Process Input Data – IO-Link Master Channels 11
16.5.3 Process Output Data – IO-Link Master Channels 13
16.6 Parameters 14
16.7 Adapting the Process Data Mapping 19
16.8 Diagnostics and Status 20
16.8.1 LED Displays Channel LEDs (C4 to C5) 20
16.8.2 Diagnostic Data 21
16.9 Using IO-Link and Turck Device DTMs 24
16.9.1 Topology Scan 24
17 IO-Link – Data Storage 25
17.1 Parameter "Data Storage Mode" = activated 26
17.2 Parameter "Data Storage Mode" = read in 27
17.3 Parameter "Data Storage Mode" = overwrite 28
17.4 Parameter "Data Storage Mode" = deactivated, clear 28
