SonixTouch Q+ Service Manual 00.053.204, Revision A Chapter 2: System Specifications
2-1
CHAPTER 2: SYSTEM SPECIFICATIONS
2.1 DIMENSIONS
Table 2-1: System Dimensions
2.2 ELECTRICAL RATINGS
Table 2-2: Electrical Ratings
Table 2-3: Fuses, Two Required
2.3 VOLTAGE ADJUSTMENT
The standard Voltage Rating for North America is 110 – 125V. The system is equipped to operate at 100 – 120V (±10%) and
200 – 240V (±10%).
Measurement Metric Value US Value
Width 53.5 cm 21 in
Depth 91.5 cm 36 in
Height, highest position (measured from top of LCD display to floor) 155 cm 61 in
Height, lowest position (measured from top of LCD display to floor) 139.7 cm 55 in
Weight (with UPS and battery) 105 kg 231.5 lbs
Weight (without UPS and battery) 80 kg 176 lbs
Input
100V—120V @ 50/60 Hz
200V—240V @ 50/60 Hz
Power Rating
120 VAC @ 7.0A
240 VAC @ 4.0A
Fuse Type 7A/250V SLO-BLO
Fuse Size 6.4 mm x 31.8 mm
Caution: Ensure the correct voltage rating has been selected before turning on the system.
