SonixTouch Q+ Service Manual 00.053.204, Revision A Chapter 6: Peripherals and Accessories
6-9
6.7 ACCESSORIES
6.7.1 Transducer Disclaimer
Certain transducers may not be available in all markets. Consult your local Ultrasonix Authorized Distributor or
Sales Representative to determine availability in your area.
6.7.2 Transducer Models
The transducers in Table 6-6 may include models that are no longer offered for sale.
Ultrasonix reserves the right to update/edit this list at any time.
Table 6-6: :Transducers (not to scale)
SA4-2/24 (Phased Array)
PA7-4/12 (Phased Array)
HST15-8/20 (Hockey Stick Linear Array) MC9-4/12 (Microconvex)
C5-2/60 and C5-2/60 GPS (Curved Array) C7-3/50 (Curved Array)
C9-5/10 (Curved Array)
BPC8-4/10 (Curved Array)
BPL9-5/55 (Linear Array)
L14-5/38 and L14-5/38 GPS (Linear Array)
L14-5W/60 (Linear Array)
L9-4/38 (Linear Array)
L40-8/12 (Linear Array)
4DC7-3/40 (Motor-driven Curved Array)
4DL14-5/38 (Motor-driven Endocavity Linear Array)
