Chapter 6: Peripherals and Accessories 00.053.204, Revision A SonixTouch Q+ Service Manual
6-8
6.6.2 Method 2: Via the TV’s PC IN Connector
Search the TV manufacturer's user guide to determine whether or not the TV’s PC IN connector will accept the
required signal format.
Table 6-5: Required Signal Format
Determine the type of connector required by the TV’s PC IN connector in order to source the correct cable:
• DVI connection > DVI to DVI cable
• HDMI connection > HDMI to DVI cable.
To Connect the TV via PC IN with a DVI Cable:
1. With both the TV and the system powered off, connect one end of the DVI cable to DVI on the system’s Back
Connectivity Panel.
2. Connect the other end of the DVI cable to PC In on the TV.
3. Ensure the TV is plugged in.
4. Power on the TV.
5. Power on the system.
6. If necessary, once there is an image on the TV, configure the TV aspect ratio setting to 4:3 (not 16:9).
To Connect the TV via PC IN with an HDMI to DVI Cable:
1. With both the TV and the system powered off, connect the DVI end of the cable to DVI on the system’s Back
Connectivity Panel.
2. Connect the HDMI end of the cable to PC In on the TV.
3. Ensure the TV is plugged in.
4. Power on the TV.
5. Power on the system.
6. If necessary, once there is an image on the TV, configure the TV aspect ratio setting to 4:3 (not 16:9).
Format Resolution V. Frequency
XGA 1024 x 768 60 Hz
