Chapter 7: Field Service Components 00.053.204, Revision A SonixTouch Q+ Service Manual
7-26
7.4 FRONT BLOCK/ULTRASOUND MODULE SERVICING
Modulo Servicing has been divided into two separate sections, the first (7.3 Replacing the Modulo) dealt with the modulo as
a discreet entity.
This, the second section, deals with front block/ultrasound module servicing.
For details on opening/removing the front block, refer to 7.4.2 and 7.4.3.
7.4.1 Accessing the Front Block/Ultrasound Module (Without Removing the Modulo)
Because the modulo – and therefore the front block/ultrasound module – is accessible from the side of the system,
not all service tasks necessitate its removal.
Equipment/Tools Required:
• #2 Phillips screwdriver.
To Access the Front Block (Without Removing the Modulo):
1. Ensure the system is powered down, unplugged and all transducers have been disconnected.
2. Remove the side shrouds (7.2.5).
7.4.2 Opening the Front Block/Ultrasound Module
To open the front block/ultrasound module without removing the modulo, follow the instructions in 7.4.1 before
continuing to the instructions below.
To open the front block/ultrasound module after
removing the modulo, follow the instructions in 7.3.1 before
continuing to the instructions below.
Equipment/Tools Required:
• #2 Phillips screwdriver.
Caution: Before doing any work with the modulo, be sure to complete sections 7.1.1 and 7.1.3 (or 7.1.5) in order to the
protect the integrity of the client's data.
Warning: Do not perform any internal system maintenance if the UPS breakers are turned on.
Caution: Always wear a grounding strap when opening and working inside the modulo.
Warning: Do not perform any internal system maintenance if the UPS breakers are turned on.
Caution: Always wear a grounding strap when opening and working inside the modulo.
