Unify OpenStage 15 Administration Manual

administration.fm
A31003-S2030-M100-11-76A9, 01/2015
OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
107
Administration
System Settings
3.5.6.2 SIP Ports
In this group of parameters, the ports for the SIP server, the SIP registrar, and the SIP gateway
are defined (for further information see Section 3.5.6.1, “SIP Addresses”), as well as the SIP
port used by the phone (SIP local).
Data required
• SIP server: Port of the SIP proxy server.
Default: 5060.
• SIP registrar: Port of the server at which the phone registers.
Default: 5060.
• SIP gateway: Port of the SIP gateway.
Default: 5060.
• SIP local: Port used by the phone for sending and receiving SIP messages.
Default: 5060.
Administration via WBM
Network > Port configuration
Administration via Local Phone
>
When changing the SIP Transport protocol from UDP/TCP to TLS, the SIP port now
also have to be changed correspondingly (e.g. SIP port from 5060 to 5061) and on
changing vice versa.
|
--- Admin
|
--- Network
SIP local
Backup proxy
RTP base
Download server (default)
LDAP server
HTTP proxy
LAN port speed
PC port speed
389
Port configuration
5060
21
Automatic
SIP gateway
5060
Submit
Reset
Automatic
0
5060
5010
SIP Server
SIP registrar
5060
5060
PC port mode
PC port autoMDIX
disabled
