Unify OpenStage 15 Administration Manual

Administration
A31003-S2030-M100-11-76A9, 01/2015
64 OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
administration.fm
IP Network Parameters
3.3.2 Protocol Mode IPv4/IPv6
An IPv4 address consists of 4 number blocks, each between 0 and 255, separated by ".".
Example:
1.222.44.123
An IPv6 address consists of 8 hexadecimal number blocks, separated by ":".
Example:
2001:0db8:85a3:08d3:1319:8a2e:0370:7347 or, if not all blocks are used:
2000:1::3
Administration via WBM
Network > General IP configuration
Set the Protocol Mode to "IPv4" or "IPv6" or both (the default setting is IPv4_IPv6). Afterwards,
click Submit.
Administration via Local Phone
|
--- Admin
|
--- Network
|
--- General IP Configuration
|
--- Protocol Mode
LLDP-MED Enabled
DHCPv6 Enabled
VLAN discovery
VLAN ID
DNS domain
Protocol Mode
Primary DNS
Secondary DNS
HTTP proxy
IPv4_IPv6
General IP configuration
Manual
;
DHCP Enabled
Submit
Reset
192.168.1.105
192.168.1.2

Unify OpenStage 15 Specifications

General

Display	Yes
Display Lines	2
Keypad	Yes
Speakerphone	Yes
Volume Control	Yes
Wall Mountable	Yes
Headset Port	Yes
Power over Ethernet (PoE)	Yes
Ethernet Port	1
Protocols	SIP
Dimensions	200 x 200 x 90 mm
Weight	0.8 kg
