Administration
A31003-S2030-M100-11-76A9, 01/2015
240 OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
administration.fm
Corporate Phonebook: Directory Settings
3.17 Corporate Phonebook: Directory Settings
3.17.1 LDAP
The Lightweight Directory Access Protocol enables access to a directory server via an LDAP
client. Various personal information is stored there, e.g. the name, organization, and contact
data of persons working in an organization. When the LDAP client has found a person’s data,
e. g. by looking up the surname, the user can call this person directly using the displayed num-
ber.
For connecting the phone’s LDAP client to an LDAP server, the required access data must be
configured. The parameters Server address and Server port specify the IP address and host-
name as well as the port used by the LDAP server. The parameter Server address specifies
the IP address of the LDAP server. The parameter Transport defines whether the phone has
to continue to use an unencrypted TCP connection to the LDAP server, or to use an encrypted
TLS connection to a separate LDAPS port on the LDAP server. Depending on the setting of
Transport the Secure Port (for TLS) or the Server port (for TCP) are to be defined. If the Au-
thentication is not set to "Anonymous", the user must authenticate himself with the server by
providing a User name and a corresponding Password. The user name and password are de-
fined by the administrator. The user name is the string in the LDAP bind request, e. g.
"C=GB,O=SIEMENS COMM,OU=COM,L=NTH,CN=BAYLIS MICHAEL". The internal struc-
ture will depend on the specific corporate directory.
For a quick guide on setting up LDAP on an OpenStage phone, please refer to Section 5.3,
“How to Set Up the Corporate Phonebook (LDAP)”.
Data required
• Server address: IP address or hostname of the LDAP server.
• Transport: Defines Transport mode, whether LDAP interface uses TCP and is unencrypt-
ed, or uses TLS and is encrypted.
Value range: "TCP", "TLS"
Default: "TCP"
• Secure Port: Defines the port of the appropriate TLS interface on LDAP server when
Transport is set to TLS.
Default: "636"
>
LDAP is available only on OpenStage 60/80 phones and on OpenStage 40 phones.
LDAP is available on OpenStage 15/20/40/60/80 with SIP V3R3.
>
The OpenStage phones support LDAPv3.
