Unify OpenStage 15 Administration Manual

Administration
A31003-S2030-M100-11-76A9, 01/2015
252 OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
administration.fm
Applications
3.19.1.2 HTTP Proxy
For the HTTP data transfer between the phone and the server hosting the remote program, an
HTTP proxy can be used.
First, the proxy itself must be configured. Enter the IP address of the proxy it in the Network >
IP configuration > HTTP proxy parameter, and the corresponding port in the Network > Port
configuration > HTTP proxy parameter.
Use proxy enables or disables the use of the proxy. If disabled, the phone connects directly to
the server. By default, the use of a proxy is disabled.
Administration via WBM
Applications > XML Applications > Add application
Applications > XML Applications > Modify/Delete application
Application name
HTTP Server address
HTTP Server port
Protocol
Program name on server
Use proxy
XML Trace enabled
Add application
http
Yes
Display name
Submit
Reset
Yes
Debug program on server
Application name
HTTP Server address
HTTP Server port
Protocol
Program name on server
Use proxy
XML Trace enabled
WR/WR
Modify/Delete application
87.106.21.36
http
No
Display name
Weather
Submit
Reset
No
Weather
8080
Debug program on server
Select application
Weather
Modify
Delete
Settings

Unify OpenStage 15 Specifications

General

Display	Yes
Display Lines	2
Keypad	Yes
Speakerphone	Yes
Volume Control	Yes
Wall Mountable	Yes
Headset Port	Yes
Power over Ethernet (PoE)	Yes
Ethernet Port	1
Protocols	SIP
Dimensions	200 x 200 x 90 mm
Weight	0.8 kg
