Administration
LAN Settings
3.2.2.2 Automatic VLAN discovery using DHCP
To automatically discover a VLAN ID using DHCP, the phone must be configured as DHCP en-
abled, and VLAN discovery mode must be set to "DHCP". LLDP-MED should be disabled.
The DHCP server must be configured to supply the Vendor Unique Option in the correct VLAN
over DHCP format. If a phone configured for VLAN discovery by DHCP fails to discover its
VLAN, it will proceed to configure itself from the DHCP within the non-tagged LAN. Under these
circumstances, network routing may probably not be correct.
Administration via WBM
Network > General IP configuration
To enable VLAN discovery via DHCP, activate the DHCPv6 Enabled checkbox and select
DHCP in the VLAN discovery option. Afterwards, click Submit.
Administration via Local Phone
To enable VLAN discovery via DHCP, activate the DHCPv6 Enabled checkbox and select
DHCP in the VLAN discovery option.
|
--- Admin
|
--- Network
|
--- General IP configuration
|
--- Protocol mode
|
--- Use LLDP-MED
|
--- Use DHCP
|
--- Use DHCPv6
|
--- VLAN discovery
|
--- VLAN ID
LLDP-MED Enabled
DHCPv6 Enabled
VLAN discovery
VLAN ID
DNS domain
Protocol Mode
Primary DNS
Secondary DNS
HTTP proxy
IPv4_IPv6
General IP configuration
DHCP
;
DHCP Enabled
Submit
Reset
192.168.1.105
192.168.1.2
