Unify OpenStage 15 Administration Manual

administration.fm
A31003-S2030-M100-11-76A9, 01/2015
OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
245
Administration
Speech
3.18.3 Audio Settings
The usage of microphone and speaker for speakerphone mode can be controlled by the ad-
ministrator.
Both microphone and loudspeaker can be switched on or off separately. By default, both micro-
phone and loudspeaker are switched on.
Administration via WBM
Speech > Audio Settings
Administration via Local Phone
The DTMF playback feature aims at the capability to play DTMF digits received using
RFC2833
coding (i.e. Rtp events) in the current active audio device (headset / loudspeaker /
handset).
>
The microphone control is not valid for OpenStage 20E, as this model has no built-
in microphone.
|
--- Admin
|
--- Speech
|
--- Audio Settings
|--- Disable microphone
|
--- Disable loudspeech
|
--- DTMF playback
Audio settings
Submit
Reset
Microphone ON-Loudspeaker ON
Mute Settings
DTMF playback
;

Unify OpenStage 15 Specifications

General

Display	Yes
Display Lines	2
Keypad	Yes
Speakerphone	Yes
Volume Control	Yes
Wall Mountable	Yes
Headset Port	Yes
Power over Ethernet (PoE)	Yes
Ethernet Port	1
Protocols	SIP
Dimensions	200 x 200 x 90 mm
Weight	0.8 kg
