Administration
A31003-S2030-M100-11-76A9, 01/2015
266 OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
administration.fm
Diagnostics
3.26.6 LLDP-MED
When the phone is connected to a switch with LLDP-MED capabilities, it can receive a VLAN
ID and QoS parameters and advertise its own network-related properties. The data is ex-
changed in TLV (Type-Length-Value) format.
Both sent and received LLDP-MED data can be monitored at the administrator interface.
For a network configuration example that shows LLDP-MED in operation, please refer to
Section 5.4, “An LLDP-Med Example”.
Displayed Data
Extended Power: Power Consumption; relevant for PoE.
Network policy (voice): VLAN ID and QoS (Quality of Service) parameters for voice trans-
port.
Network policy (signalling): VLAN ID and QoS (Quality of Service) parameters for sig-
nalling.
LLDP-MED capabilities: The LLDP-MED TLVs supported by the phone and the switch as
well as the specific device class they belong to.
MAC_Phy configuration: Identifies the possible duplex and bit-rate capability of the send-
ing device, its current duplex and bit-rate capability, and whether theses settings are the
result of auto-negotiation during the initialization of the link, or of manual set override ac-
tions.
System capabilities: The devices advertise their potential and currently enabled func-
tions, e. g. "Bridge", "Telephone".
TTL: Time To Live. This parameter determines how long the TLVs are valid. When expired,
the device will send a new set of TLVs.
>
For details on LLDP-MED, please refer to the ANSI/TIA-1057 standard.
