Unify OpenStage 15 Administration Manual

administration.fm
A31003-S2030-M100-11-76A9, 01/2015
OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
217
Administration
Transferring Phone Software, Application, and Media Files
3.16.3.2 Download/Update Phone Software
If applicable, phone software should be deployed using the DLS (Deployment Service). Alter-
natively, the download can be triggered from the web interface or from the Local phone menu.
When the download has been successful, the phone will restart and boot up using the new soft-
ware.
Start Download via WBM
In the File transfer > Phone application dialog, set After submit to "start download" and press
the Submit button.
Start Download via Local Phone
1. In the administration menu, set the focus to Phone app.
2. Press the g key. A context menu opens. In the context menu, select Download. The
download will start immediately.
>
When Phone Software was upgraded to V3R3 there may be displayed a downgrade
protection message.
|
--- Admin
|
--- File Transfer
|
--- Phone app
Phone application
Download method
FTP Server address
FTP Server port
21
192.168.1.150
FTP account
FTP username
FTP password
phone
FTP path
HFA/OpenStage
Submit
Reset
FTP
HTTPS base URL
Filename
opera_bind.img
After submit
start download
Use defaults

Unify OpenStage 15 Specifications

General

Display	Yes
Display Lines	2
Keypad	Yes
Speakerphone	Yes
Volume Control	Yes
Wall Mountable	Yes
Headset Port	Yes
Power over Ethernet (PoE)	Yes
Ethernet Port	1
Protocols	SIP
Dimensions	200 x 200 x 90 mm
Weight	0.8 kg
