Unify OpenStage 15 Administration Manual

Administration
A31003-S2030-M100-11-76A9, 01/2015
56 OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
administration.fm
LAN Settings
3.2.2.1 Automatic VLAN discovery using LLDP-MED
As an alternative, the VLAN ID can be configured by the network switch using LLDP-MED (Link
Layer Discovery Protocol-Media Endpoint Discovery). If this option is selected, and the switch
provides an appropriate TLV (Type-Length-Value) element containing the VLAN ID, this VLAN
ID will be used. If no appropriate TLV is received, DHCP will be used for VLAN discovery.
Administration via WBM
Network > General IP configuration
To enable VLAN discovery via LLDP-MED, activate the LLDP-MED Enabled checkbox and se-
lect LLDP-MED in the VLAN discovery option. Afterwards, click Submit.
Administration via Local Phone
To enable VLAN discovery via LLDP-MED, set the Use LLDP-MED option to Yes and select
LLDP-MED in the VLAN discovery option.
|
--- Admin
|
--- Network
|
--- General IP configuration
|
--- Protocol mode
|
--- Use LLDP-MED
|
--- Use DHCP
|
--- Use DHCPv6
|
--- VLAN discovery
|
--- VLAN ID
LLDP-MED Enabled
DHCPv6 Enabled
VLAN discovery
VLAN ID
DNS domain
Protocol Mode
Primary DNS
Secondary DNS
HTTP proxy
IPv4_IPv6
General IP configuration
LLDP-MED
;
DHCP Enabled
Submit
Reset
192.168.1.105
192.168.1.2
;
