Unify OpenStage 15 Administration Manual

Startup
A31003-S2030-M100-11-76A9, 01/2015
42 OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
inbetriebnahme.fm
Quick Start
2.3.9 Registering at Phone Administration
For registration at the OpenStage SIP V3R3 SIP server, a SIP user ID and password must be
provided by the phone. The following procedure describes the configuration using the web in-
terface (see Section 2.3.1, “Accessing the Web Interface (WBM)”; if the web interface is not
applicable, please refer to Section 3.5.7, “Authenticated Registration”) for configuration via the
local menu.
1. In the administration menu, select System > Registration. The Registration dialog opens.
2. Make sure that SIP server address and SIP registrar address contain the IP address of
your OpenScape Voice server. If not provided by DHCP or DLS, enter the appropriate val-
ues. If the phone is to register with a gateway, enter the appropriate SIP Gateway ad-
dress.
3. In the Server type field, select "OS Voice".
4. In Realm, enter the SIP realm the targeted user/password combination refers to.
5. In the User ID and Password fields, enter the user name/password combination for the
phone.
SIP server address
SIP registar Address
SIP gateway address
Registration
SIP Survivability
SIP Session
SIP Addresses
192.168.1.165
Session timer enabled
Session duration (seconds)
Registration timer (seconds)
3600
3600
Server type
HiQ8000
Submit
Reset
192.168.1.165
Backup registration allowed
Backup proxy address
Backup registration timer (seconds)
3600
;
Backup transport
Backup OBP flag
UDP
Realm
User ID
Password
