administration.fm
A31003-S2030-M100-11-76A9, 01/2015
OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
201
Administration
Dialing
3.13.4 Dial Plan
OpenStage phones may optionally use a dial plan residing on the phone. By means of the dial
plan, the phone can infer from the digits entered by the user that a complete call number has
been entered, or that a particular prefix has been entered. Thus, the dialing process can start
without the need to confirm after the last digit has been entered, without delay or with a config-
urable delay. The standard timer, which is found on the WBM under User menu > Configuration
> Outgoing calls > Autodial delay (seconds), is overridden if a dial plan rule is matched.
A dial plan consists of rules defining patterns, timeouts and actions to be performed when a
pattern is matched and/or a timeout has expired. The phone can store one dialplan, which can
contain up to 48 different rules.
It is very important that the phone’s dial plan does not interfere with the dial plan in the SIP
server, PBX, or public network.
The dial plan can be created and uploaded to the phone using the DLS (please refer to the De-
ployment Service Administration Manual). The DLS can also export and import dial plans in
.csv format. For details about the composition of a dial plan, please refer to Section 5.5, “Dial
Plan”.
The current dial plan, along with its status (enabled/disabled) and error status can be displayed
on the WBM via Diagnostics > Fault trace configuration > Download dial plan file.
With software version V2R2, the Dial plan ID and the Dial plan status is displayed in the local
menu.
To make use of the dial plan facility, the following requirements must be met:
• A correct dial plan is loaded to the phone.
• In the user menu, Allow immediate dialing is enabled.
• Dial plan enabled is checked.
Administration via WBM (User menu)
User > Configuration > Outgoing calls > Allow immediate dialing
