Unify OpenStage 15 Administration Manual

administration.fm
A31003-S2030-M100-11-76A9, 01/2015
OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
157
Administration
Free Programmable Keys
3.8.11 Deflect a Call
On key press, an incoming call is deflected to the specified destination.
The label displayed to the left of the key is defined in Key label <key number>.
The target destination is defined in the Destination parameter.
Administration via WBM
System > Features > Program keys > Deflect
3.8.12 Shift Level
Shift the level for the programmable keys. When activated, the functions assigned to the shifted
level are available on the keys.
The label displayed to the left of the key is defined in Key label <key number>.
Administration via WBM
System > Features > Program keys > Shift
3.8.13 Phone-Based Conference
Establishes a three-party conference from an active call and held call.
The label displayed to the left of the key is defined in Key label <key number>.
>
This feature can be enabled or disabled under System > Features > Feature access
(see Section 3.6, “Feature Access”).
Key.label 3
Deflect
Deflect
Submit
Reset
Destination
3335
Key.label 8
Shift
Shift
Submit
Reset

Unify OpenStage 15 Specifications

General

Display	Yes
Display Lines	2
Keypad	Yes
Speakerphone	Yes
Volume Control	Yes
Wall Mountable	Yes
Headset Port	Yes
Power over Ethernet (PoE)	Yes
Ethernet Port	1
Protocols	SIP
Dimensions	200 x 200 x 90 mm
Weight	0.8 kg
