LAN Settings
3.2 LAN Settings
3.2.1 LAN Port Settings
The OpenStage phone provides an integrated switch which connects the LAN, the phone itself
and a PC port. By default, the switch will auto negotiate transfer rate (10/100 Mb/s, 1000 Mb/s
with OpenStage 15/20/40/60/80 G) and duplex method (full or half duplex) with whatever equip-
ment is connected. Optionally, the required transfer rate and duplex mode can be specified
manually using the LAN port speed parameter.
The PC Ethernet port is controlled by the PC port mode parameter. If set to "Disabled", the PC
port is inactive; if set to "Enabled", it is active. If set to "Mirror", the data traffic at the LAN port
is mirrored at the PC port. This setting is for diagnostic purposes. If, for instance, a PC running
Ethereal/Wireshark is connected to the PC port, all network activities at the phone’s LAN port
can be captured.
When PC port autoMDIX is enabled, the switch determines automatically whether a regular
MDI connector or a MDI-X (crossover) connector is needed, and configures the connector ac-
cordingly.
Data required
• LAN port speed / LAN port type: Settings for the ethernet port connected to a LAN
switch.
Value range: "Automatic," "10 Mbps half duplex", "10 Mbps full duplex", "100 Mbps half du-
plex", "100 Mbps full duplex" and, additionally, for OpenStage 20/40/60/80 G, "1 Gbps full
duplex"
Default: "Automatic"
• PC port speed / PC port type: Settings for the ethernet port connected to a PC.
Value range: "Automatic," "10 Mbps half duplex", "10 Mbps full duplex", "100 Mbps half du-
plex", "100 Mbps full duplex" and, additionally, for OpenStage 20/40/60/80 G, "1 Gbps full
duplex"
Default: "Automatic"
• PC port mode / PC port status: Controls the PC port.
Value range: "disabled", "enabled", "mirror".
Default: "disabled"
>
In the default configuration, the LAN port supports automatic detection of cable con-
figuration (pass through or crossover cable) and will reconfigure itself as needed to
connect to the network.
>
Removing the power from the phone, or a phone reset/reboot will result in the tem-
porary loss of the network connection to the PC port.
