Unify OpenStage 15 Administration Manual

Administration
A31003-S2030-M100-11-76A9, 01/2015
254 OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
administration.fm
Applications
3.19.1.3 Modify an Existing Application
An existing application can be modified by changing its parameters. Please ensure to select
the desired application before changing the parameters.
Administration via WBM
Applications > XML applications > Modify/Delete application
Administration via Local Phone
|
--- Admin
|
--- Applications
|
--- XML
|
--- <Application to be modified>
|--- Display name
|--- Application name
|--- Server address
|--- Server port
|--- Protocol
|--- Program name
|--- XML trace enabled
|
--- Debug program name
Application name
HTTP Server address
HTTP Server port
Protocol
Program name on server
Use proxy
XML Trace enabled
WR/WR
Modify/Delete application
87.106.21.36
http
No
Display name
Weather
Submit
Reset
No
Weather
8080
Debug program on server
Select application
Weather
Modify
Delete
Settings

Unify OpenStage 15 Specifications

General

Display	Yes
Display Lines	2
Keypad	Yes
Speakerphone	Yes
Volume Control	Yes
Wall Mountable	Yes
Headset Port	Yes
Power over Ethernet (PoE)	Yes
Ethernet Port	1
Protocols	SIP
Dimensions	200 x 200 x 90 mm
Weight	0.8 kg
