Administration
Diagnostics
View Data From WBM
Diagnostics > LLDP-MED TLVs
View Data From Local Menu
If both sent and received values are concordant, OK is appended to the parameter. If not, an
error message is displayed.
|
--- Admin
|
--- Network
|
--- LLDP-MED operation
|--- Extended Power
|--- Network policy (voice)
|--- LLDP-MED cap’s
|--- MAC_Phy config
|--- System cap’s
|
--- TTL
LLDP-MED TLV’s
Received: Mon Oct 27 10:41:14 2013
Channel ID TLV Data
.ID = 00:3E:37:01:20:01
TTL TLV Data
.records = 120
System Caps TLV Data
.Supported = Other, Repeater
.Enabled = Other, Repeater
Sent
Received
Sent: Mon Oct 27 10:41:14 2013
Channel ID TLV Data
.ID = 163.165.2.105
TTL TLV Data
.records = 120
System Caps TLV Data
.Supported = Bridge, Telephone
.Enabled = Telephone
