inbetriebnahme.fm
A31003-S2030-M100-11-76A9, 01/2015
OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
23
Startup
Assembling and Installing the Phone
2. Only if Power over Ethernet (PoE) is NOT supported:
Plug the power supply unit into the mains. Connect the plug-in power supply unit to the
jack at the bottom of the phone.
OpenStage 40 + 2nd Key Module Power Class 2
OpenStage 40 G
2
,OpenStage 40 G US
2
Power Class 3
OpenStage 40 G or OpenStage 40 G US + 2nd Key
Module
Power Class 3
OpenStage 60/80
3
Power Class 3
OpenStage 60/80 + 2nd Key Module Power Class 3
OpenStage 60/80 G
3
Power Class 3
OpenStage 60/80 G + 2nd Key Module External power unit required
1 Includes 1 Key Module 15.
2 Includes 1 Key Module.
3 Includes 1 Key Module + USB-Extension with Acoustic Unit.
7
The order no. for the plug-in power supply is region specific:
EU: C39280-Z4-C510
UK: C39280-Z4-C512
USA: C39280-Z4-C511
Model Power Consumption/Supply
