Administration
Diagnostics
•OBEX service
Involved with Bluetooth accesses to the phone.
Bluetooth is available only on OpenStage 60/80 phones.
• OpenStage client management
Provides a means by which other services within the phone can interact with the database.
• Password management service
Verifies passwords used in the phone.
• Phonebook
Responsible for the phonebook application.
• POT service (not present with V2)
Takes over control of basic telephony if the callview application fails.
• Performance Marks
Aid for measuring the performance of the phone. For events triggered by the user, a per-
formance mark is written to the trace file, together with a timestamp in the format hh:mm:ss
yyyy.milliseconds, and information about the event. The timespan between two perfor-
mance marks is an indicator for the performance of the phone.
• Physical interface service
Handles any interactions with the phone via the keypad, mode keys, fixed feature buttons,
clickwheel and slider.
• Security Log Service
Handles Security Log Service messages.
• Service framework
This is the environment within which other phone services operate. It is involved in the
starting and stopping of services.
• Service registry
Keeps a record of all services currently running inside the phone.
• Sidecar service
Handles interactions between the phone and any attached sidecars.
• SIP call control
Contains the call model for the phone and is associated with telephony and call handling.
• SIP messages
Traces the SIP messages exchanged by the phone.
>
The trace level must be set to "TRACE" or "DEBUG".
>
After changing the level for the tracing of SIP messages, the phone must be reboo-
ted. Otherwise the changes would have no effect.
