Administration
A31003-S2030-M100-11-76A9, 01/2015
294 OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
administration.fm
Diagnostics
Non-compressing/ Compressing codecs threshold values:
• Lost packets (per 1000 packets): When the number of lost packets exceeds this maxi-
mum value during the observation interval, a report is created.
Default: 10
• Consecutive lost packets: When the number of lost packets following one another ex-
ceeds this maximum value during the observation interval, a report is created.
Default: 2
• Consecutive good packets: When the number of good packets following one another
falls below this minimum value, a report is created.
Default: 8
• Resend last report: If checked, the previous report is sent once again on pressing Sub-
Submit.
Value range: "Yes", "No"
Default: "No"
The transmission of report data can be triggered manually by pressing Send now in the local
menu.
Administration via WBM
Diagnostics > QoS Reports > Generation
Generation
Codec independent threshold values
Report interval (seconds)
Observation interval (seconds)
60
10
20
Minimum session length (100 millisecond units)
Report mode
EOS Threshold exceeded
Maximum jitter (milliseconds)
20
100
Average round trip delay (milliseconds)
Non-compressing codec threshold values
Lost packets (per 1000 packets)
Consecutive lost packets
10
8
Consecutive good packets
2
Compressing codec threshold values
Lost packets (per 1000 packets)
Consecutive lost packets
10
8
Consecutive good packets
2
Resend last report
Submit
Reset
