Unify OpenStage 15 Administration Manual

Technical Reference
A31003-S2030-M100-11-76A9, 01/2015
342 OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
referenz.fm
Menus
View
2011-10-16 20:22:33
00 Terminal number: 3339
01 SIP server: 192.168.1.230
02 SIP port: 5060
03 SIP registrar: 192.168.1.230
04 SIP registrar port 5060
05 SIP gateway: 192.168.1.230
06 SIP gateway port 5060
07 SIP transport: UDP
08 SIP local: 5060
09 Server features: No
10 DNS results: 5060
11 Multiline: No
12 Registered lines: 5060
13 Backup active: Yes
14 Backup proxy: 192.168.1.148
15 Use secure calls: No
16 SDES status: 0
17 Secure SIP server: 0
18 Software version: V3R0.50.0 110924
19 Display message: None
20 Last restart: 2011-10-10T23:59:01
21 Memory free: 65733K free
22 Protocol mode: IPv4
23 IP4 address: 192.168.1.235
24 IP4 subnet mask: 255.255.255.0
25 IP4 default route: 192.168.1.2
26 Primary DNS: 192.168.1.105
27 Secondary DNS: 192.168.1.2
28 IP4 route 1 IP: None
29 IP4 route 1 gateway: None
30 IP4 route 1 mask: None
31 IP4 route 2 IP: None
32 IP4 route 2 gateway: None
33 IP4 route 2 mask: None
34 IP6 address: None
35 IP6 prefix length: None
36 IP6 global gateway: None
37 IP6 link local addr: None
38 IP6 route 1 dest: None
39 IP6 route 1 pref len: None
40 IP6 route 1 gateway: None
41 IP6 route 2 dest: None
42 IP6 route 2 pref len: None
43 IP6 route 2 gateway: None
44 MAC address: 0001e325eaca
45 Discovery mode: Manual
46 DHCP re-use: No
47 DHCPv6: Yes
48 DHCPv6 re-use: No
49 LAN port type: 0
50 PC port status: None
51 PC port type: 0
52 PC port autoMDIX: No
53 VLAN ID: None
54 QoS Layer 2: None
55 QoS Layer 2 voice: 5
56 QoS Layer 2 signalling: None
57 QoS Layer 2 default: 0
58 QoS Layer 3: Yes
59 QoS Layer 3 voice: EF / 46
60 QoS Layer 3 signalling: AF31 / 26
61 LLDP-MED operation: None
62 XML application:
None
63 XML app config:
View
