Unify OpenStage 15 Administration Manual

beispiele.fm
A31003-S2030-M100-11-76A9, 01/2015
OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
387
Examples and HowTos
How to Set Up the Corporate Phonebook (LDAP)
The following examples show the relations between GUI field names, the attribute labels used
in the template, and exemplary mappings to LDAP attributes.
Generic Example (Standard Attributes)
>
In an LDAP template for OpenStage 15/20/40, the entries must be sorted according
to the sequential number of the template labels, as shown in the example underne-
ath.
For OpenStage 60/80 phones, it is also recommended to use pre-sorted entries,
which will reduce the use of resources.
OpenStage Field LDAP
Template
Lables
LDAP Attribute Example
Value
Last name ATTRIB01 sn Doe
First name ATTRIB02 givenName John
Business 1 ATTRIB03 telephoneNumber 9991234
Business 2 ATTRIB04 facsimileTelephoneNumber 9992345
Mobile ATTRIB05 mobile 017711223344
Private ATTRIB06 homePhone 441274333444
Company ATTRIB07 o Example Inc.
Address 1 ATTRIB08 departmentNumber 0815
Address 2 ATTRIB09
Job function ATTRIB10 title Product Manager
Email ATTRIB11 mail doe@example.com
ATTRIB12 any LDAP attribute optional for wildcard
search

Unify OpenStage 15 Specifications

General

Display	Yes
Display Lines	2
Keypad	Yes
Speakerphone	Yes
Volume Control	Yes
Wall Mountable	Yes
Headset Port	Yes
Power over Ethernet (PoE)	Yes
Ethernet Port	1
Protocols	SIP
Dimensions	200 x 200 x 90 mm
Weight	0.8 kg
