Configuring Devices for the DME
DME Admin Guide 205
4. Publish the .sdp file (via FTP) to the root folder on the DME using FTP. After you FTP
the file, there will be a live RTP stream in the DME that can be served in a variety of
ways. For example you can reflect the stream as a multicast relay or auto-unicast it to
another DME. See
Configure a DME Stream for more information.
Playback Examples
More Configuration Examples
The configuration examples below refer to the configuration diagram found in the
Configuring Devices for the DME topic.
The examples explain various ways you can configure stream types.
Configure an RTMP Stream for the DME
VEMS Mystro (Live
Entered URL)
vbrtsp://172.1.1.1/vbStream1S1
vbhttp://172.1.1.1/vbStream1T1.sdp
iOS
http://<dme_ip_address>/HLS/<stream_name>/playlist.m3u8
Desired Result Acquire an RTMP stream from RMD and RMS
Solution • RMD: In-1
• RMS:
In-2
Desired Result Use the stream to create an HLS and multicast RTP output
Solution • RMD and HLS: In-1 to Out-6
• RMS and HLS:
in-2 to Out-6
• RMD to Multicast:
In-1 to Out-10 to Out-7
• RMS to Multicast:
In-2 to Out-10 to Out-7
Desired Result Acquire an RTMP stream from another source, such as VBoss, which is
also being archived on VBoss.
Solution In-5 Archiving on VBOSS not currently supported.
