Configuring Devices for the DME

DME Admin Guide 203

5. When done click OK and Finish and the H.264 for Flash option will be added to the

Outputs menu as a selectable output option.

Stre am to th e DME w ith RMS 1.3

You can use RMS to send an H.264 unicast push or a multicast output stream to the DME.

With both methods you will need to publish the .sdp file to the DME

 To configure an RMS stream for a DME:

1. Open RMS and enter a destination address on the Broadcast page. In the

Destination

Address field (Figure 1) enter a multicast IP address (for example 239.2.127.254) or the

unicast IP address of the DME.

Note: When entering metadata (e.g. Session Info, Origin E-Mail, etc.) be sure to remove

any leading spaces.
