VIDEOJET DataFlex 6530 - 3.1.1.4 Ribbon Detector PCB; 3.1.1.5 Carriage Assembly and Linear Slide; 3.1.1.6 Belt and Idler Pulley Assembly

3-4 Videojet DataFlex 6530 Service Manual - Rev AA
Main Parts
3.1.1.4 Ribbon Detector PCB
3.1.1.5 Carriage Assembly and Linear Slide
3.1.1.6 Belt and Idler Pulley Assembly
Figure 3-6: Ribbon Detector PCB
Linear SlideCarriage Assembly
Figure 3-7: Carriage Assembly and Linear Slide
1
2
3
4
5
6
Figure 3-8: Belt and Idler Pulley Assembly
1. Printhead Drive Pulley
2. Carriage Idler Pulley
3. Carriage Belt
4. Carriage Drive Pulley
5. Printhead Idler Pulley
6. Printhead Belt
