VIDEOJET DataFlex 6530 - 3.2.5 Cable Connections

3-14 Videojet DataFlex 6530 Service Manual - Rev AA
Main Parts
3.2.5 Cable Connections
Figure 3-18 displays the details of the printer cable connections.
PRINTER
PSU
HMI
0 1
Mains
Power
RS232
PSU-HMI
Connector
USB
USB
Power
Switch
Encoder
Input/
Output
Ethernet (x3)
Interconnecting
Cable
Figure 3-18: Cable Connections
