VIDEOJET DataFlex 6530 - 3.1.1.7 Motors

Videojet DataFlex 6530 Service Manual - Rev AA 3-5
Main Parts
3.1.1.7 Motors
Note: The ribbon motor with sensor changes position depending on hand of the printer. The sensor is
always on the waste ribbon side.
2
3
4
1
Figure 3-9: Motors
1. Printhead Stepper Motor with
sensor
2. Ribbon Stepper Motor with
sensor
3. Ribbon Stepper Motor
4. Carriage Stepper Motor
