3-6 Videojet DataFlex 6530 Service Manual - Rev AA
Main Parts
3.1.1.8 Main PCB
3.1.2 CLARiTY HMI Display and Power Supply Unit (PSU)
The HMI-PSU consists of a removable touch screen display and power supply unit. The
connections to the HMI-PSU is as shown in the Figure 3-15.
Micro SD Card
Main PCB
Figure 3-10: Main PCB
1
3
2
5
Figure 3-11: Display and Power Supply Unit
1. Touch Screen Display
2. Power Supply unit (PSU)
3. PSU-HMI Connector
