Videojet DataFlex 6530 Service Manual - Rev AA 4-7
Installation
The CLARiTY Configuration Manager (Figure 4-7) is a PC software program, that provides the
following basic features:
• Setting all the printer variables
• Saving/retrieving a set of variable values to a PC file for later/repeated use
• Downloading a set of variables for non-volatile (permanent) memory storage in the
printer
• Uploading a set of variables from the printer for review/comparison/modification
• Updating the system software
• Saving/retrieving language files
• Saving/retrieving job, font, and graphics files
• Configuring master/slave functionality
• Snapshot of CLARiTY screens
As a result, the CLARiTY HMI display only retains the availability of a small number of
operating variables for the user to change. Apart from making the CLARiTY control system
more simple and user-friendly, it also provides an increased level of printer system integrity,
because the configuration variables cannot be accessed from the printer itself, but only from a
connected PC.
If the printer is installed to run in a standalone mode (i.e., the printer is not networked), the PC is
only linked briefly (via the RS232 serial or ethernet port) for the period of upload/download of
the variables (a few seconds). The PC would then be removed.
In a networked environment, system administrators could have direct access to the printer,
while line operators are limited to accessing only the operating variables that are relevant to
them.
4.7.2 Installing the CLARiTY Configuration Manager
CLARiTY Configuration Manager is available in the USB with the Operator Manual. To operate
the USB, the system requires Windows XP, NT or Windows 7.0 operating system with minimum
5 MB capacity and ethernet or serial port. The installation routine commences automatically. To
install the CLARiTY Configuration Manager on a PC:
1. Insert the Operator Manual USB.
2. Click on CLARiTY Configuration Manager in the home page.
3. Run the CLARiTYConfig.exe file.
4. Follow the on-screen instructions to install the software.
The software is installed in the PC and is ready for use.
