3-12 Videojet DataFlex 6530 Service Manual - Rev AA
Main Parts
3.2.3 Interlocks and Annunciation
The 15-pin D-type (male) connector, located on the side of the printer unit is available for
connecting with a variety of useful interlock and annunciation signals.
Table 3-2 summarizes the input and output connections.
Note: For more information on configuring the inputs and outputs, refer “Working with the Configurable
Inputs and Outputs” on page 4-17.
Pin Purpose
1+24 V
2 External input #1 PNP 24 V
30 V
4 External input #2 PNP 24 V
5 External input #3 PNP 24 V
6 Relay output #1 N/C
7 Relay output #1 common
8 Relay output #1 N/O
9 Relay output #2 common
10 Relay output #2 N/O
11 PNP 24 V Output #1
12 0 V
13 PNP 24 V Output #2
14 Encoder Phase B input
15 Encoder Phase A input
Table 3-2: Input and Output Connections
