Videojet DataFlex 6530 Service Manual - Rev AA 4-13
Installation
4.7.5 Saving the Changes in the Printer
To make the changes effective, proceed as follows:
1. Click the printer icon in the left-hand pane to open the printer controls at the bottom pane of
the window.
2. Click the download button to update the printer with the changes that you have made to the
parameters.
A dialog box opens with the message “The parameters to be downloaded have not been
saved to an archive”.
3. Touch OK to continue with the download.
4. The new parameters are active when the download is complete.
Note: Unless steps 1 to 4 are performed, none of the parameter changes become effective in the printer.
4.7.6 Archiving the Current Parameters
The set of parameters can be saved as an archive and are stored on the PC. The archive can be
loaded into the Configuration Manager and downloaded to the printer again at a later date to
revert to the archived set of parameters.
Once the printer has been configured, it is recommended that all the parameters be uploaded
into the PC, and saved as an archive.
To archive the current parameters, proceed as follows:
1. Right click the Archives folder in the left-hand panel.
2. Select the New Save option from the pop-up menu.
3. Change the default Archive name by overwriting the name in the pop up dialog box as
required. Select OK. A file for the new save appears under the archives folder with a name
containing the current time and date.
4. Once saved, the name of the archive can be changed in the bottom panel, by selecting the file,
changing the name as required and clicking the Apply button.
4.7.7 Loading a Saved Archive
To load an archive that was saved previously, proceed as follows:
1. Locate the archive in the left panel and right click on it.
2. Choose Load from the pop-up menu.
The archived parameters are displayed on the right-hand pane.
3. Click the printer icon from the left-hand panel and click the Download button to load the
archive of parameters to the printer.
Note: To put the new settings into effect, the CLARiTY user interface must be rebooted. If you have any
questions concerning your network, contact your IT administrator.
