VIDEOJET DataFlex 6530 - Page 74

5-4 Videojet DataFlex 6530 Service Manual - Rev AA
Menu Structure
Diagnostics (Continued) Printhead (Continued) Inputs (Continued) Printhead Position Sensor
Ribbon Waste Position Sensor
Optical Calibration Sensor
iAssure Sensor
Motor Volts
24 Volts Supply
Printhead Volts
Printhead Temperature
Controller PCB Temperature
Outputs Printhead Position
Printhead In/Out
External Relay Output 1 (7 & 8)
External Relay Output 2 (9 & 10)
External PNP Output 3 (11)
External PNP Output 4 (13)
Green LED
Red LED
Optical Calibration LEDs
iAssure LEDS
General Printer Mode
Printer Hand
Printer Width
Printing Mode
High Throughput Mode
Print Test Image
Menu
Table 5-9: Menu Structure (Continued)
