Watlow F4T Controller • 40 • Chapter 2 Configuration Using Composer
3. Click Open.
Duplicating a Profile
To duplicate a profile:
• Right-click the profile and click Duplicate in the pop-up menu.
Or
• Click the profile, then click the Duplicate at the bottom of the profile list.
Note:
The duplication process automatically appends the duplicated profile to the end of the
profile list.
Note:
If a profile is locked with a password and duplicated, the duplicated profile is not pass-
word protected.
Note:
The name of the duplicate profile is the original profile's name with the words "Copy of"
added to the beginning. The result may be truncated so as not to exceed 20 characters.
Deleting Profiles
To delete a profile:
• Right-click the profile, click Delete in the pop-up menu and then click OK to confirm
Or
• Click the profile, click Delete button at the bottom of the profile list and then click OK
to confirm.
Or
• Click the profile, press the Delete key on the computer keyboard and click OK to con-
firm.
Opening the Step Editor
To open the step editor:
• Click any step in the step list.
Adding Steps
To add a step to a profile:
• Right-click a step and choose Insert Step After or Add Step to End in the pop-up
menu.
Or
• Click the Add new step button in the step list.
Hint:
• When clicking on "Add new step...", if a step is selected, a duplicate of the selected step
is added, if no step is selected, a duplicate of the last step is added.

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
