Watlow F4T Controller • 39 • Chapter 2 Configuration Using Composer
End Action
Set what the control loop does after the profile is completed.
Options:
• User: the loop controls at the Set Point setting prior to execution of the profile.
• Off: the loop's control mode is set to Off.
• Hold: the loop's Set Point is set to the last value used in the profile.
Note:
To anticipate and plan for expected control action at the end of a profile, an End step
should always be included as the last step in a profile. If not included within the profile,
a parameter within the control or cascade loop called "Profile End Action" will determine
which option above is active. End Action (if used within the profile), always takes prece-
dence over Profile End Action.
Opening the Profile View
To view the profile listing:
1. From the device menu choose Profiles.
2. Click Profiles to bring up the profile listing.
Creating Profiles
To create a new profile in the controller:
1. Click the Add new profile.. button.
2. If desired, click in the Name field and change the profile's name.
Note:
The default name is New Profile. The user should give each profile a unique name. A pro-
file name is limited to 20 characters
Saving a Profile to a Storage Device
To export a copy of a profile from the controller to a file:
1. Select the profile by clicking it in the profile list.
2. Click Export at the bottom of the profile list.
3. Us the Save As dialog to edit the name and select the desired location and click the
Save button.
Hint:
• Export is an option on the profile pop-up menu.
Note:
A profile that has a password applied will be saved with the password.
Loading a Profile
To load a profile previously saved on the computer in to controller memory:
1. Click Import.
2. Use the open dialog to locate and select the desired profile file.
