Watlow F4T Controller • 41 • Chapter 2 Configuration Using Composer
Inserting Steps
To insert a new step ahead of an existing step:
• Right-click the step and choose Insert Step Before in the pop-up menu.
Or
• Click the step and then click the Insert Before button at the bottom of the step list.
Deleting Steps
To delete a step:
• Right-click the step and choose Delete Step in the pop-up menu
Or
• Click the step and then click the Delete button at the bottom of the step list
Or
• Click the step and press the Delete key on the computer keyboard
Password Protect a Profile
To avoid inadvertent changes to a profile, apply password protection to it.
To set a password for a profile:
1. Click the Password button.
2. In the dialog box enter a password (10 characters maximum).
3. Re-enter the same password to verify it.
4. Click OK
Note:
A password protected profile requires the password be entered to edit but not to copy it
or to delete it. If the profile is duplicated, the duplicate is not password protected.
Changing or Removing a Password from a Protected Profile
To change or remove a profile's password, the password must be known.
To change a profile's password:
1. Select the profile by clicking it in the profile list.
2. Enter the password and click OK.
3. Click the Password button.
4. Enter a new password (10 characters maximum).
5. Re-enter the same password to verify it.
6. Click OK.
To remove a profile's password:
1. Select the profile by clicking it in the profile list.
2. Enter the password and click OK.
3. Click the Password button.
4. Click the Remove button.

Watlow F4T Specifications

General

Inputs	Thermocouple, RTD, mA, V
Outputs	Relay, SSR, mA, V
Communication	Ethernet, Modbus RTU
Data Logging	Yes
Certifications	CE, UL, cUL, RoHS
Control Modes	PID, On/Off
Power Supply	100 to 240 VAC
Operating Temperature	0 to 50°C
Enclosure Rating	IP65
Display	4.3 in. (109 mm) color touch panel LCD
Control Loops	Up to 4
