CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
The copyfunction is used to transfer thecontentof the parametersfrom
one inverter to another.Theinverters must be of the same type (voltage/
current and the same software version must be installed.
Range
[Factory Setting]
Parameter
Unit
Description / Notes
Example:versionV1.60

(x
=
1,y
=
6
and
z
=
0)storedintheHMIpreviously
I.
Inverter version: V1.75

(x´ = 1, y´ = 7 and z´ = 5)
P215 = 2

E10 [(y = 6)

(y´ = 7)]
II.
Inverter version: V1.62

(x´ = 1, y´ = 6 and z´ = 2)
P215 = 2

normal copy [(y = 6) = (y´ = 6)]
The procedure is as follows:
1.
Connect the Keypadto the inverter from which the parameters will be
copied(InverterA).
2.
Set P215 = 1 (INV

HMI) to transfer the parameter values from the
InverterAto the Keypad.
3.
Press the
key. P204 resets automatically to 0 (Off) after the
transfer is completed.
4.
Disconnect the Keypad from the inverter.
5.
Connect the same Keypad to the inverter to which the parameters
will be transferred (Inverter B).
6.
Set P215 = 2 (HMI

INV) to transfer the content of the Keypad
memory(containing the InverterAparameters) to Inverter B.
7. Press the
key. When P204 returns to 0, the parameter transfer
has been concluded.NowInvertersAandB havethesameparameter
values.
Note:
Incase InvertersAandB are not of the same model, check the values of
P295(RatedCurrent) and P296(RatedVoltage) of Inverter B.
If the inverters are driving different motors, check the motor related
parameters of InverterB.
8.
To copy the parameters content of the Inverter A to other inverters,
repeat items 5 to 7 of this procedure.
NOTE!
IftheHMIhasparameterssavedofa “differentversion” thaninstalled
in the inverter to which it is trying to copy the parameters, the
operation will not be executed and the inverter willdisplaythe error
E10 (Error: not permitted Copy Function). “Different Version” are
those that are different in “x” or “y”, supposing that the numbering
of Software Versions is described as
Vx.yz
.
