CFW-09-
QUICK PARAMETER REFERENCE
17
Parameters
Function
Adjustable Range
Factory
Unit
User's
Page
Setting
Setting
4 = Torque Current (Vector)
5 = Output Current
6 = PID Process Variable
7 = Active Current (V/F)
8 = Power (kW)
9 = PID Setpoint
10
=
Positive Torque Current
11 = Motor Torque
12 = PLC
13 = Dead Zone for
Speed Indication
14 = Motor Voltage
P254
Analog Output AO2 Gain
0.000 to 9.999
1.000
-
169
P255
Analog Output AO3 Function
0 = Speed Reference
2 = Real Speed
-
169
(Requires Optional I/O Expansion
1 = Total Reference
Board EBA)
2 = Real Speed
3 = Torque Current
Reference (Vector)
4
=
Torque Current (Vector)
5 = Output Current
6 = PID Process Variable
7 = Active Current (V/F)
8 = Power (kW)
9 = PID Setpoint
10
= Positive Torque Current
11 = Motor Torque
12 = PLC
13 =
Not Used
14 = Motor Voltage
15 to 63 = Exclusive WEG use
P256
Analog Output AO3 Gain
0.000 to 9.999
1.000
-
170
P257
Analog Output AO4 Function
0 = Speed Reference
5 = Output Current
-
170
(Requires optional I/O Expansion
1 = Total Reference
Board EBA)
2 = Real Speed
3 = Torque Current
Reference (Vector)
4 = Torque Current (Vector)
5 = Output Current
6 = PID Process Variable
7 = Active Current (V/F)
8 = Power (kW)
9 = PID Setpoint
10
=
Positive Torque Current
11 = Motor Torque
12 = PLC
13 = Not Used
14 = Motor Voltage
15 to 63 = Exclusive WEG use
P258
Analog Output AO4 Gain
0.000 to 9.999
1.000
-
170
P259
Dead Zone for Speed Indication
0 to P134
1000
rpm
171
