CFW-09-
QUICK PARAMETER REFERENCE
18
Parameters
Function
Adjustable Range
Factory
Unit
User's
Page
Setting
Setting
Digital Inputs
P263
(1)
Digital Input DI1 Function
0 = Not Used
1 = Start/Stop
-
172
1 = Start/Stop
2 = General Enable
3 = Fast Stop
P264
(1)
Digital Input DI2 Function
0 = FWD/REV
0 = FWD/REV
-
172
1 = Local/Remote
2 = Not Used
3 = Not Used
4 = Not Used
5 = Not Used
6 = Not Used
7 = Not Used
8 = Reverse Run
P265
(1) (8)
Digital Input DI3 Function
0 = Not Used
0 = Not Used
-
172
1 = Local/ Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = Increase E.P.
6 = Ramp 2
7 = Not Used
8 = Forward Run
9 = Speed/Torque
10 = JOG+
11 = JOG-
12 = Reset
13 = Fieldbus
14 = Start (3 wire)
15 = Man/Auto
16 = Not used
17 = Disables Flying Start
18 = DC Voltage Regulator
19 = Parameter Setting
Disable
20 = Load user
21 = Timer (RL2)
22 = Timer (RL3)
P266
(1)
Digital Input DI4 Function
0 = Not used
0 = Not Used
-
172
1 = Local/ Remote
2 = General Enable
3 = JOG
4 = No external Fault
5 = Decrease E.P.
6 = Ramp 2
7 = Multispeed (MS0)
8 = Reverse Run
9 = Speed/Torque
10 = JOG+
