WEG CFW-09 - Page 18

CFW-09-
QUICK PARAMETER REFERENCE
19
11 = JOG-
12 = Reset
13 = Fieldbus
14 = Stop (3 wire)
15 = Man/Auto
16 = Not used
17 = Disables Flying Start
18 = DC voltage regulator
19 = Parameter Setting
Disable
20 = Load User
21 = Timer (RL2)
22 = Timer (RL3)
P267
(1)
Digital Input DI5 Function
0 = Not Used
3 = JOG
-
172
1 = Local/ Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = Increase E.P.
6 = Ramp 2
7 = Multispeed (MS1)
8 = Fast Stop
9 = Speed/Torque
10 = JOG+
11 = JOG-
12 = Reset
13 = Fieldbus
14 = Start (3 wire)
15 = Man/Auto
16 = Not Used
17 = Disables Flying Start
18 = DC Voltage Regulator
19 = Parameter Setting
Disable
20 = Load User
21 = Timer (RL2)
22 = Timer (RL3)
P268
(1)
Digital Input DI6 Function
0 = Not Used
6 = Ramp 2
-
173
1 = Local/ Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = Decrease E.P.
6 = Ramp 2
7 = Multispeed (MS2)
8 = Fast Stop
9 = Speed/Torque
10 = JOG+
11 = JOG-
Parameters
Function
Adjustable Range
Factory
Unit
User's
Page
Setting
Setting
