QUICK PARAMETER REFERENCE
20
Parameters
Function
Adjustable Range
Factory
Unit
User's
Page
Setting
Setting
12 = Reset
13 = Fieldbus
14 = Stop (3 wire)
15 = Man/Auto
16 = Not Used
17 = Disables Flying Start
18 = DC voltage regulator
19 = Parameter setting
disable
20 = Load user
21 = Timer (RL2)
22 = Timer (RL3)
P269
(1)
Digital Input DI7 Function
0 = Not Used
0 = Not used
-
173
(Requires optional I/O
1 = Local/ Remote
expansion board EBA or EBB)
2 = General Enable
3 = JOG
4 = No External Fault
5 = Not Used
6 = Ramp 2
7 = Not Used
8 = Fast Stop
9 = Speed/Torque
10 = JOG+
11 = JOG-
12 = Reset
13 = Fieldbus
14 = Start (3 wire)
15 = Man/Auto
16 = Not Used
17 = Disables Flying Start
18 = DC Voltage Regulator
19 = Parameter Setting
Disable
20 = Load User
21 = Timer (RL2)
22 = Timer (RL3)
P270
(1)
Digital Input DI8 Function
0 = Not used
0 = Not used
-
173
(Requires optional I/O
1 = Local/Remote
expansion board EBA or EBB)
2 = General Enable
3 = JOG
4 = No External Fault
5 = Not Used
6 = Ramp 2
7 = Not Used
8 = Fast Stop
9 = Speed/Torque
10 = JOG+
11 = JOG-
12 = Reset
