CFW-09-
QUICK PARAMETER REFERENCE
21
Parameters
Function
Adjustable Range
Factory
Unit
User's
Page
Setting
Setting
13 = Fieldbus
14 = Stop (3 wire)
15 = Man/Auto
16 = Motor Thermistor
17 = Disables Flying Start
18 = DC Voltage Regulator
19 = Parameter Setting
Disable
20 = Not Used
21 = Timer (RL2)
22 = Timer (RL3)
Digital Outputs
P275
(1)
Digital Ouput DO1 Function
0 = Not used
0 = Not Used
-
180
(requires optional I/O
1 = N* > Nx
expansion board EBA or EBB)
2 = N > Nx
3 = N < Ny
4 = N = N*
5 = Zero Speed
6 = Is > Ix
7 = Is < Ix
8 = Torque > Tx
9 = Torque < Tx
10 = Remote
11 = Run
12 = Ready
13 = No Fault
14 = No E00
15= No E01+E02+E03
16 = No E04
17 = No E05
18 = (4 to 20) mA OK
19 = Fieldbus
20 = FWD
21 = Proc.Var. > VPx
22 = Proc. Var. < VPy
23 = Ride-Through
24 = Pre-charge OK
25 = Fault
26 = Enabled Hours > Hx
27 = Not Used
28 = Not Used
29 = N > Nx and Nt > Nx
30 = Brake (Actual Speed)
31 =
Brake (Total Reference)
32 = Overweight
33 = Slack Cable
34 = Torque Polarity +/-
